Siemens - Cilindrische zekering 3Nc2240 - 3NC2240
Bekijk voorraad en prijs na inlog
Belangrijke kenmerken
Grootte - 22 x 58 mm
Uitschakelkarakteristiek - Overig
Nom. (meet)spanning - 690 V
Nom. (meet)stroom - 40 A
Model - Overig
Verpakking
1 per stuk(s)
Voorraadartikel: Ja
Artikelnummer TU
1587780
Leverancierscode
3NC2240
EAN
4011209570122
Commercieel bestelnummer
3NC2240
HGS code
195601
Douanenummer
85361050
Grootte:
22 x 58 mm
Uitschakelkarakteristiek:
Overig
Nom. (meet)spanning:
690 V
Nom. (meet)stroom:
40 A
Model:
Overig
Met slagpin:
Nee
Bedrijfsklasse:
aR (deelbereik stroomomvormerbeveiliging)
Spanningstype:
AC
Afschakelvermogen:
100 kA
Nom. werkfrequentie:
45 t/m 62 Hz
Vermogensverlies bij nom. stroom:
9 W
SITOR cylindrical fuse link, 22x58 mm, 40 A, aR, Un AC: 690 V, Un DC: 700 V, DC according to UL As an important component of the SENTRON protection components for electrical installations, the SITOR fuse system offers effective protection of people, equipment and systems through safe shutdown in the event of overload or short-circuits. Due to their super-fast switch-off characteristics, compared to conventional NH fuses, as well as their very good characteristic curve fidelity, power semiconductors are also reliably protected. SENTRON circuit protection devices - A safe choice.
Identificatie- EAN: 4011209570122
- Artikelnummer leverancier: 3NC2240
- Artikelomschrijving leverancier: SITOR cylindrical fuse link, 22x58 mm, 40 A, aR, Un AC: 690& V, Un DC:
- Artikelnummer Technische Unie: 1587780
