Festo - Pneumatic cylinder dsm-8-180-p-a - 173198
Bekijk voorraad en prijs na inlog
Belangrijke kenmerken
Inner diameter - 8 mm
Dual-action - Yes
Mounting method - With internal (female) thread
Operating pressure - 3.5 t/m 8 bar
Operating medium - Compressed air ISO 8573-1:2010 [7:4:4]
Verpakking
1 per stuk(s)
## Geen retour mogelijk ##
Artikelnummer TU
7665661
Leverancierscode
173198
EAN
4052568004804
Commercieel bestelnummer
DSM-8-180-P-A
HGS code
188403
Douanenummer
85444290
Inner diameter:
8 mm
Dual-action:
Yes
Mounting method:
With internal (female) thread
Operating pressure:
3.5 t/m 8 bar
Operating medium:
Compressed air ISO 8573-1:2010 [7:4:4]
Ambient temperature:
0 t/m 60 °C
Material seal:
TPE-U(PU)
Material piston rod:
High alloy steel, non-corrosive
Festo pneumatic cylinder, inner diameter 8mm, dual-action yes, mounting method with internal (female) th, operating pressure 3.5 - 8bar, operating medium compressed air ISO 8573-1, ambient temperature 0 - 60°C, basic weight for 0 mm stroke 85g, material seal TPE-U(PU),
