Festo - Pneumatic cylinder dsm-10-180-p - 173193
Bekijk voorraad en prijs na inlog
Belangrijke kenmerken
Inner diameter - 10 mm
Dual-action - Yes
Mounting method - With internal (female) thread
Operating pressure - 2.5 t/m 8 bar
Operating medium - Compressed air ISO 8573-1:2010 [7:4:4]
Verpakking
1 per stuk(s)
## Geen retour mogelijk ##
Artikelnummer TU
7681096
Leverancierscode
173193
EAN
4052568142476
Commercieel bestelnummer
DSM-10-180-P
HGS code
188403
Douanenummer
85444290
Inner diameter:
10 mm
Dual-action:
Yes
Mounting method:
With internal (female) thread
Operating pressure:
2.5 t/m 8 bar
Operating medium:
Compressed air ISO 8573-1:2010 [7:4:4]
Ambient temperature:
0 t/m 60 °C
Material seal:
TPE-U(PU)
Material piston rod:
High alloy steel, non-corrosive
Festo pneumatic cylinder, inner diameter 10mm, dual-action yes, mounting method with internal (female) th, operating pressure 2.5 - 8bar, operating medium compressed air ISO 8573-1, ambient temperature 0 - 60°C, basic weight for 0 mm stroke 140g, material seal TPE-U(PU),
